Description
■ High-Efficient Energy Storage Batteries.
■ Modular design providing escort in emergency.
■ The safest lithium solar battery material (LFP) battery
■ Integrated battery management system (BMS)
■ Battery system designed for PV household application
■ Longer cycle life 6000 cycles @ 80% DOD, 25°C
■ Built-in WiFi Smart Module
| Technical Data | LP20-24200 | LP20-24280 | LP20-48200 | LP20-48280 | ||
| Nominal Voltage | 25.6V | 51.2V | ||||
| Nominal Capacity | 200Ah | 280Ah | 200Ah | 280Ah | ||
| Nominal energy | 5120Wh | 7168Wh | 10240Wh | 14336Wh | ||
| Life Cycles | 6000 cycles @ 80% DOD, 25°C | |||||
| Recommended Charge Voltage | 57.6V | |||||
| Recommended Charge Current | 40A | 50A | 40A | 50A | ||
| End Of Discharge Voltage | 44V | |||||
| Standard Method | Charge | 40A | 50A | 40A | 50A | |
| Discharge | 100A | 125A | 100A | 125A | ||
| Maximum Continuous Current | Charge | 150A | 150A | 150A | 150A | |
| Discharge | 150A | 150A | 150A | 150A | ||
| BMS Cut-Off Voltage | Charge | 29.2 V (3.65V/Cell) | 58.4 V (3.65V/Cell) | |||
| Discharge | 22.0V (2.75V/Cell) | 44.0V (2.75V/Cell) | ||||
| Temperature | Charge | 0 ~ 45°C | ||||
| Discharge | -10 ~ 55°C | |||||
| Storage Temperature | -5~35°C | |||||
| Shipment voltage | ≥25.6V | ≥51.2V | ||||
| Module Parallel | Up to 15 units | |||||
| Communication | CAN2.0/RS232/RS485 | |||||
| Case Material | SPPC | |||||
| Machine Dimension (H*W*D) (mm) | / | / | 540*498*438 | / | ||
| Package Dimension (W*H*D) (mm) | wooden box | / | / | 620*610*568 | / | |
| N.W (kg) | / | 88 | / | |||
| G.W (kg) | wooden box | / | / | 105 | / | |
| * Variations in dimensions and weights may occur due to production batches. | ||||||
| Charge Retention And Capacity Recovery Capability | Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention rate≥90%, Recovery rate of charge≥90 |
|||||
| Certification & Standards | CE-EMC (EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) UN38.3/ MSDS |
|||||
